• This helps the user to identify pages that have been
split because the size of the paper is smaller than the
size of the document received. (When A5 is used to
print an A4 size document, for example.)
1
Repetition of data when the
received page is longer than the
printer paper
0: Off
1: On
1: Default. 10 mm of the trailing edge of the previous page
are repeated at the top of the next page.
0: The next page continues from where the previous page
stopped without any repeated text.
2
Prints the date and time on received
fax messages
0: Disabled
1: Enabled
This switch is only effective when user parameter 02 - bit 2
(printing the received date and time on received fax
messages) is enabled.
1: The machine prints the received and printed date and
time at the bottom of each received page.
3-7 Not used Do not change the settings.
Printer Switch 01 [SP No. 1-103-002]
No FUNCTION COMMENTS
0-2 Not used Do not change the settings.
3-4
Maximum print width used in the
setup protocol
Bit 4: 0, Bit 3: 0 = Not used
Bit 4: 0, Bit 3: 1 = A3
Bit 4: 1, Bit 3: 0 = B4
Bit 4: 1, Bit 3: 1 = A4
These bits are only effective when bit 7 of printer switch 01
is “1”.
5-6 Not used Do not change the settings.
7
Received message width restriction
in the protocol signal to the sender
0: Disabled
1: Enabled
0: The machine informs the transmitting machine of the print
width depending on the paper size available from the
paper feed stations.
Refer to the table on the next page for how the machine
chooses the paper width used in the setup protocol (NSF/
DIS).
Bit Switches
67
To Next Page
