4-7
Page separation setting when sub
scan compression is forbidden
00-0F (0-15 mm: Hex)
Default: 6 mm
Page separation threshold (with reduction disabled with
switch 03-0 above).
For example, if this setting is set to "10", and A4 is the
selected paper size:
If the received document is 10 mm or less longer than A4,
then the 10 mm are cut and only 1 page prints.
If the received document is 10 mm longer than A4, then the
document is split into 2 pages.
Printer Switch 04 [SP No. 1-103-005]
No FUNCTION COMMENTS
0-4
Maximum reducible length when length reduction is enabled with switch 03-0 above.
<Maximum reducible length> = <Paper length> + (N x 5mm)
“N” is the decimal value of the binary setting of bits 0 to 4.
Bit 4 Bit 3 Bit 2 Bit 1 Bit 0 Setting
0 0 0 0 0 0 mm
0 0 0 0 1 5 mm
0 0 1 0 0 20 mm
1 1 1 1 1 155 mm
For A5 sideways and B5 sideways paper
<Maximum reducible length> = <Paper length> + 0.75 x (N x 5mm)
5-6
Length of the duplicated image on the next page, when page separation has taken place.
Bit 6: 0, Bit 5: 0 = 4 mm
Bit 6: 1, Bit 5: 0 = 10 mm
Bit 6: 0, Bit 5: 1 = 15 mm
Bit 6: 1, Bit 5: 1 = Not used
7 Not used. Do not change the setting.
Printer Switch 05 - Not used (do not change the settings)
Printer Switch 06 [SP No. 1-103-007]
Bit Switches
69
