No. Items Image Reference
22 Front IR Sensor page 62
23 Speaker (with Rubber) page 57
24 Front Cover page 45
25 PSU page 57
26
Harness
(PSU to Main Board)
page 57
27
Harness
(Laser Bank to LD Driver
Board)
page 63
28 Power Socket page 67
29 LD Driver Board page 56
3. Replacement
