No. Items Image Reference
30
Harness
(LD Driver Board to Main
Board)
page 56
31 Keypad Board page 47
32 Keypad page 47
33 Keypad (Enter) page 47
34 IO Board page 52
35 Audio Board page 52
36
Harness
(PSU to LD Driver Board)
page 57
Parts List
