Ridder RW800 - Install Instructions

Electrical
RW series RW45 RW240–600 RW800 RW70/140
Duty cycle [kb]
Applicable for intermient duty, duty class s3-35%, with a
maximum running me of 25 minutes.
Maximum current
Refer to the nameplate of the electric motor.
Power
Thermal protecon EM
[°C (°F)]
3-wire electric motors are thermally protected with a PTO switch
with a switching temperature of 140 °C (284 °F).
Cable glands
M16x1.5 mm/M20x1.5 mm. Also refer to §5.2.
Mains voltage
115 V - 60 Hz • •* - -
230 V - 50 Hz
240 V - 60 Hz
• • • •
* Not applicable: - RW600 - -
Ambient
RW series RW45 RW240–600 RW800 RW70/140
Protecon rang IP54*
Ambient temperature [°C (°F)] 0–60 °C (32–140 °F)
* IP55 only applicable if in idencaon.
4. INSTALL INSTRUCTIONS
Installaon is only permied to approved personnel.
Do a check of the supplied parts in the table that follows. Use these parts with the mounng plate
(selecon) which is applicable. Refer to §4.4.
Parts list *
500000 Motor Gearbox RW 1-phase ** 1x
* Minimum parts list: Motor gearbox without oponal parts and accessories.
** Motor gearboxes have spring washers and bolts M10x20 (2x), M10x25 (3x) or M12x25 (4x). Item numbers
from 500000.
Installaon (general)
• This product manual gives only informaon about the installaon of RW motor-gearboxes and
related connecons to output-shas (installaon opons).
• Informaon about the dierent operated systems is not (or not fully) given or gives only general
informaon.
Ridder Drive Systems B.V.
T +31 (0)341 416 854 - F +31 (0)341 416 611 - I ridder.com
14
