2.4 Symbols and abbreviaons
This secon tells about used symbols and abbreviaons in this manual. The table that follows gives
the descripons.
Symbol Description Symbol Description
ACS Automac control-system PLC PLC Control
BOS Basic Output Shas (RW) PTO Thermal-overload protecon-switch
C Common connecon PZ Cross head “Pozidriv”
D Model with connuous worm-sha P21/1 Auxiliary contact K21
EM, M Electric motor, Motor P22/1 Auxiliary contact K22
EMC Electromagnec compability P71, P72 Automac-control contacts (ACS)
ESD ElectroStac Discharge RLL Ridder LogicLink
ES11,ES12 Duty switch RLS/RSU RLS Limit-switch system
ES21,ES22 Safety switch RLS/RSU RMC Ridder MotorControl
F1 Fuse rpm revoluons per minute
HEX Hexagonal width-across-ats RPT Ridder PolyTelescope
I Current in Amperes (A) RPU Ridder PosioningUnit
IP Internaonal Protecon Rang RRD Ridder RackDrive
K
Designaon sprocket (assembled
conguraon)
RSD Ridder ScreenDrive
RSU Limit-switch system
kb
Maximum running me in minutes
(kb = KurzBetrieb/ Short operaon)
RW Motor gearbox
SBI Standard Bolt-Installaon
K11 Auxiliary relays (safety switches) SID Screw-in depth
K21, K22
Reversing relay (suciently specied)
for direcon-of-rotaon
SS (S21) System switch (S21)
SW Width-across-ats
K81
Auxiliary relay: 1-phase, 3-wire to
5-wire
S11 Manual switch (bridged safety circuit)
S21 (SS) System switch (SS)
L Model with winch sha S111 Manual switch (MC)
L1 Voltage source TRA Model for built-on rack unit
MC Manual Control TRI Rack drives TRI
MPCB/
Q41
Motor-Protecon Circuit-Breaker
TRN Rack drives TRN
TX Screw head “Torx”
N Neutral wire T1 Safety transformer (EN 61558)
NC “normally closed” U1, U2 Motor connecon
NO “normally open” V1 Motor connecon
PE Protecve earth W1, W2 Motor connecon
PH Cross head “Phillips”
