Ridder RW800 - Tightening-Torque Motor-Connections

EMC Interference
Problems with electromagnec interference must be prevented. For a correct funconal operaon
possibly precauons, such as an EMC mains-lter, are necessary.
Inducon
Problems with inducon must be prevented. Inducon can cause an interference with the
electronics.
Inducon can have many causes such as:
• Cable lengths
• External sources
• Too many cables together.
5.4 Tightening-torque motor-connecons
Tighten the motor connecons with the correct ghtening
torque!
• M4 connecons: 2 Nm
• M5 connecons: 3 Nm.
It is necessary to obey EMC-conformity. This prevents problems with
electromagnec interference.
Separaon of cables is necessary. This prevents problems with
inducon.
2 Nm!
\M4
\M5
3 Nm!
