5.2 Electrical material
• A minimum conductor cross-secon of 1.5 mm² is applicable to the cables in the general
wiring diagrams. For the used components, electrical material and cable lengths the necessary
conductor cross-secon can be dierent.
RW243/245/400/600\RW800\RW70/140 [RSU]
• Motor-current connecon through the RSU limit-switch system is not permitted!
The limit-switch system is applicable for the currents that follow:
• 45 mA–130 mA at 24 V AC/DC
• A maximum of 100 mA at 115/230/240 V.
RW45\RW241/242 [RLS]
• Motor-current connecon or control-circuit connecon through the RLS limit-switch is permitted.
The limit-switch system is applicable for the currents that follow:
• 45 mA–130 mA at 24 V AC/DC
• A maximum of 4 A at 115 V
• A maximum of 2.25 A at 230/240 V.
Use only applicable components and electrical material.
Always refer to the related informaon and manuals.
The RSU limit-switch system is NOT applicable for motor-current
connecon through the limit switches.
