4.3 Sprockets
• Usually Ridder installs sprockets onto the two basic output shafts (BOS) of most models (general
designaon: RW).
• Some models (such as RW-LK, RW-D, RW-LD) have:
• One special output-sha (LK) plus one basic output sha (BOS)
• One special output-sha (D) plus two basic output shas (BOS)
• Two special output-shas (L + D). (The L-sha is for installaon of a drum.).
• Some models or shas (BOS and/or special shas) are supplied without sprockets.
Thus it is possibly necessary, if applicable for the conguraon, to:
❶ Install necessary (oponal) sprockets on output shas or
❷ Interchange sprockets with necessary (oponal) sprockets on output shas.
Refer to the illustraon (step ❶ and ❷) that follows for the conguraon of sha keys (a, b),
retaining rings (c) and ring (d).
For more informaon on item numbers and models refer to the Ridder catalog or website at
ridder.com.
* Sha LK-model: Installaon of a drum is also possible. Refer to §4.7/4.8.
** Sha L-model is for installaon of a drum. Refer to §4.7/4.8.
Basic output shas [BOS] Output sha LK Output sha D
HEX 3 mm
M6 x 8 mm
Model: RW Model: RW-LK Model
2x BOS 1x Sha-LK*
+ 1x BOS
RW-D: 1x Sha-D
+ 2x BOS
RW-LD: 1x Sha-D
+ 1x Shaft-[L]**
