Cable glands
The RW motor-gearbox has (installed) cable glands M20x1.5 mm and/or M16x1.5 mm to put
through the motor connecons (EM) and the limit-switch cables (RLS/RSU).
The condions and starng points that follow are applicable:
• Always put only one cable through one cable gland.
• Use a cable with a conductor-diameter of Ø6.0–12.0 mm and a ghtening torque of 5.0 Nm for
cable glands M20x1.5 mm.
Use a cable with a conductor-diameter of Ø5.0–10.0 mm and a ghtening torque of 2.5 Nm for
cable glands M16x1.5 mm.
• Make sure that water flows away from the cable glands (cable roung: make loops if necessary).
Obey the procedure that follows:
❶ Loosen the cable gland.
❷ Remove the sealing plug*.
❸ Put the cable through the cable gland.
❹ Tighten the cable glands with the correct tool and ghtening torque.
* If your decision is not to use this cable gland, make sure to put the sealing plug back. Tighten the
cable gland with the correct tool and ghtening torque!
Make sure that all openings are correctly sealed with cable glands
or with inially installed blind plugs. This prevents problems with
moisture and/or the IP protecon rang.
Ø6.0–12.0 mm
M20x1.5/M16x1.5
- 5 Nm
- 2.5 Nm
Ø5.0–10.0 mm
