Chapter 2 Front Panel Reference RIGOL
User’s Guide for DP1116A
Utility Settings
Press Utility, the backlight of this key goes on and the instrument enters the
associated system setting interface, see figure below:
Figure 2-17 System setting interface
Table 2-3 The System setting interface explanations
Set or reset the LAN parameter, view the ID number of the
USB device, set the GPIB address.
Set the parameters about the system, including Language,
Power-on value, Screen brightness, Overtemperature, Beeper,
Self-test and view the system information.
Enter the calibration interface.
Set the timing output parameters about the channel.
Exit the Utility function.
