Chapter 5 Specifications RIGOL
User’s Guide for DP1116A
5-1
Chapter 5 Specifications
The specification and operating characteristics are based on the instrument having
been operated continuously for 30 minutes under the specified operating
temperature.
Note: All the specifications below apply to both the two scales unless where noted.
Model
DP1116A
Scale
16 V/10 A
32 V/5 A
Output Ratings (0℃ - 40℃)
Voltage
0 - 16 V
0 - 32 V
Current
0 - 10 A
0 - 5 A
Overvoltage Protection
0.1 V - 35.2 V
Overcurrent Protection
0 .1 A - 11 A
Load Regulation± (output percentage + offset)
Voltage
< 0.01% + 2 mV
Current
< 0.005% + 250 μA
Line Regulation± (output percentage + offset)
Voltage
< 0.01% + 2 mV
Current
< 0.01% + 250 μA
Ripple and Noise (20 Hz~20 MHz)
Normal Mode Voltage
< 350 μV rms/3 mVpp
Normal Mode Current
< 2 mA rms
Accuracy 12 Months
[1]
(25℃±5℃)± (output percentage + offset)
Program
ming
Voltage
0.05% + 10 mV
Current
0.2% + 10 mA
Read
Back
Voltage
0.05% + 5 mV
Current
0.15% + 5 mA
Resolution
Programming
1 mV/1 mA
Read Back
1 mV/1 mA
Meter
1 mV/1 mA
Transient Response Time
Less than 50 μs is spent on recovering the voltage within 15 mV when the output
current changes from full load to half load or half to full.
