Chapter 3 Remote Control
The DP1116A Programmable DC Power Supply confirms to the LXI-C standards (1.2)
and provides two ways for remote controlling, which are Web and Command.
Web Control
To control you DP1116A via web page, please follow the instructions below:
1. LAN Setting
Use a Net cable to access your DP1116A into LAN, then press I/O → LAN to
enter the setting interface of LAN (see figure below) and follow the “I/O
Settings” in Chapter 2 to set the LAN and obtain an IP address.
Figure 3-1 LAN setting interface
2. Remote Control
Input the obtained IP address in the internet browser to enter an interface as
shown in figure below, then click “Web Identification Indicator” and a message
“Target identified!” will be shown on the screen of the instrument. To exit the
message, click this item again.
