b. Temporarily secure the cable by attaching it to the pedestal using a long zip tie.
6. Use a 17 mm wrench to remove the lag bolt securing the top plate of the pedestal.
7. Remove the pedestal from the crate.
NOTICE
It is recommended to use proper hoisting equipment to perform thisoperation.
8. Place the pedestal on a piece of cardboard to prevent damaging the unit.
CAUTION
Make sure that the pneumatic tube and the ground cable located inside the base of the pedestal
are not pinched during thisoperation.
CAUTION
The weight of the pedestal isapproximately 54 kg (119 lb). Proceed with caution.
9. Remove the screwsthat hold the wooden framesto the crate.
10. Remove the wooden frames.
27
