4. Remove the plate from the base by opening and closing it while lifting.
5. Fasten the URcontrol box to the control box support plate using the four (4)screwsthat were previously removed.
NOTICE
Make sure that the cabinet door is on the side opposite to the retaining tabs.
6. Secure the assembly to the base by inserting the retaining tabsin their respective cutouts.
7. Tilt the control box back and forth to reassemble the hinging mechanism.
33
