NOTICE
The optional safety kit requires the interfacing of a reset push button.
If there isno optional safety kit in the scope of delivery, the hole left by the optional reset push
button is filled with material.
21. Run the W72 and W82 cables from the operator station to the base.
22. Connect the W72 cable to the W70 cable.
23. Connect the W82 cable to the W80 cable.
NOTICE
Optional extension cables(W71 and W81) can be used to displace the operator station.
39
