Roche Diagnostics
Operator’s Manual · Version 3.1 B-109
Cedex Bio System 6 Special operations
Exporting data
pev_yyyymmddhhmmss.csv
The following figure is an example of a test result file that was opened in a
spreadsheet tool.
Column Title Description
Instr Instrument ID (always 30 for Cedex Bio)
Msg Message Type:
9 Process event
Index 191 Reagent usage changed
192 Calibrator assigned valued changed
193 QC assigned valued changed
199 Other process event
App Application code
Date Date when the event took place
Time Time when the event took place
SW-Version Software version installed on the instrument
Serial Serial number of the instrument
Event Description of the event
User User name ($SYS$ "system user" = ??? if nobody is logged in)
Test Short name of the application
Table 37 Explanations on process events
Figure 3 Example of spreadsheet representation of a test result raw data file
