Operator’s Manual · Version 3.1 A-65
Cedex Bio System 3Hardware
Technical specifications
Technical specifications
Physical dimension
Power requirements
Power requirements ISE unit
Measurement principles
Environmental conditions
Throughput
Samples
NOTICE
Every effort has been made to ensure that all the information contained in these specifica-
tions is correct at the time of printing. However, Roche Diagnostics reserves the right to
make any changes necessary without notice as part of ongoing product development.
Width 720 mm
Depth 550 mm
Height 480 mm
Weight Approximately 35 kg
Line voltage 100-125 V and 200-240 V (-15%, +10%)
Line frequency 50 Hz (±5%) and 60 Hz (±5%)
Power consumption 250 VA
Insulation coordination Installation category II (IEC 61010-1)
Main fuse T6. 3 A H 250 V
Low voltage fuses T3. 15 A L 250 V
Battery Lithium 3.6 V 2.3 Ah SL-360/S
Line voltage 100-240 V (±10%)
Line frequency 50 Hz (±5%) and 60 Hz (±5%)
Supply voltage 19-24 V DC, Min. 2A
Power consumption 70 VA
Insulation coordination Installation category II (IEC 61010-1)
Absorbance photometry (enzymes, substrates, drugs of abuse)
Potentiometry ISE (ion selective electrodes) Na
+
, K
+
, Cl
-
Temperature Running conditions: 15-32°C
Transport and storage: -25 to +60°C
Humidity Running conditions: 30-80% at 15-32°C, non
condensing.
Transport and storage: 10-95%, non condensing
Pollution Degree 2 (IEC 61010-1)
Altitude Max. 2000 m above sea level
Photometric 85 tests/h max.; 60 tests/h consolidated (with typical test
panel)
ISE 180 tests/h max.; 60-100 tests/h consolidated
(photometric and ISE mixed)
Sample handling Manually by operator
Time to first result 5-10 min (photometric measurements)
2 min (ISE measurements)
