Roche Diagnostics
A-80 Operator’s Manual · Version 3.1
4Software Cedex Bio System
Working with the user interface
2
Use the scroll bar to display the hidden information.
e
For details on scrolling, see Scrolling on page A-73.
Messages
Messages are displayed in two ways:
o Immediate feedback on user actions is displayed in a pop-up message screen.
o Information concerning a problem that occurred during operation is reported in
the alarm monitor.
Message screen
Message screens are displayed automatically as soon as the message is generated.
Read the message and press to close the screen.
Alarm monitor
Messages concerning an irregularity that occurred during operation can be viewed in
the alarm monitor. The alarm LED alerts you when such messages are generated. It is
turned off when all alarm messages are confirmed.
The Alarm button is always active, even if nobody is logged on the system.
Alarm button and LED
Figure A-45 Message screen
A Alarm LED B Alarm button
Figure A-46 Alarm LED
