Roche Diagnostic
s
E-38
Operatorโs Manual ยท Version 3.1
13
ISE operation
Cedex
Bio System
Cleaning the ISE tower off the inst
rument
Finishing the task
18
Switch on the instrument.
19
Wait for initialization to finish.
20
Log on to the system.
21
Perform the maintenance action
Clean ISE Tower Automatically
.
e
See
Clean ISE tower automatically
on page
E-50.
427
429
