Roche Diagnostics
A-40 Operator’s Manual · Version 3.1
3Hardware Cedex Bio System
Covers and panels
Main cover Provides access to:
o Rotor
o Reagent disk
o Cuvettes
o Reagent bottles
o Photometer unit
You open this cover whenever you need to handle cuvettes, reagent bottles, or the
reagent disk. A green LED indicates that you should place an item, a yellow LED that
you should not open the main cover.
To open the cover, press the release button at the underside of the front of the cover.
When you should close the cover an acoustic signal is sounded and the
system icon
on the System Status screen
turns red.
Rear service flap Provides access to:
o Computer boards
o Power supply
o Transfer unit
o Degasser
This flap should be opened by service representatives only.
Shut down the system and switch off the instrument before you open this cover and
remove the two side panels before opening this flap.
Right side panel Provides access to:
o Syringe assembly
Remove this panel as instructed during maintenance actions or shut down the system
and switch off the instrument before you remove it.
Right service flap Provides access to:
o Photometer unit
o Sample area
o Touchscreen
o Data management computer
Open this panel as instructed during maintenance actions or shut down the system
and switch off the instrument before you open it.
Printer panel Provides access to:
o Printer paper.
You can open this flap any time as long as the printer is not printing.
To open the panel, press the release button.
