Rockwell Automation Publication 2080-QS004C-EN-E - October 2023 41
Chapter 8 How to Implement an Instruction Block
Your Ladder Diagram program should look as follows.
2. Locate the ANY_TO_TIME instruction in the Conversion folder of the Instruction Toolbar. Drag-and-drop the instruction onto the new
rung.
