Adapter Parameters B-3
PowerFlex® 755 Drive Embedded EtherNet/IP Adapter User Manual
Publication 750COM-UM001A-EN-P
33 [Port Number]
Displays the drive port to which the embedded
EtherNet/IP adapter is dedicated. This is
always Port 13.
Default: 13
Value: 13
Type: Read Only
34 [DLs From Net Act]
Displays the number of actual controller-to-
drive Datalinks that the drive is using based on
the I/O connection opened by the controller.
Default: 0
Minimum: 0
Maximum: 16
Type: Read Only
35 [DLs To Net Act]
Displays the number of actual drive-to-
controller Datalinks that the controller is using
based on the I/O connection opened by the
controller.
Default: 0
Minimum: 0
Maximum: 16
Type: Read Only
36 [BOOTP]
Configures the adapter to use BOOTP so that
you can set its IP address, subnet mask, and
gateway address with a BOOTP server. When
this parameter is disabled, you must use the
adapter parameters to set these addressing
functions.
Default: 1 = Enabled
Values: 0 = Disabled
1 = Enabled
Type: Read/Write
Reset Required: Yes
37 [Net Addr Src]
Displays the source from which the adapter
node address is taken. This will be switches,
Parameters 40-43 [IP Addr Cfg x], or
BOOTP. It is determined by the settings of the
octet switches on the adapter. See Setting the
IP Address Switches on page 2-2 for details.
Default: 0 = Switches
Values: 0 = Switches
1 = Parameters
2 = BOOTP
Type: Read Only
38
39
40
41
[IP Addr Cfg 1]
[IP Addr Cfg 2]
[IP Addr Cfg 3]
[IP Addr Cfg 4]
Sets the bytes in the IP address.
Important: To set the IP address using these
parameters, Parameter 36 - [BOOTP] must
be set to “0” (Disabled).
Default: 0
Default: 0
Default: 0
Default: 0
Minimum: 0
Maximum: 255
Type: Read/Write
Reset Required: Yes
42
43
44
45
[Subnet Cfg 1]
[Subnet Cfg 2]
[Subnet Cfg 3]
[Subnet Cfg 4]
Sets the bytes of the subnet mask.
Important: To set the subnet mask using
these parameters, Parameter 36 - [BOOTP]
must be set to “0” (Disabled).
Default: 0
Default: 0
Default: 0
Default: 0
Minimum: 0
Maximum: 255
Type: Read/Write
Reset Required: Yes
Parameter
No. Name and Description Details
255 . 255 . 255 . 255
[IP Addr Cfg 1]
[IP Addr Cfg 2]
[IP Addr Cfg 3]
Set with Octet Switch on
Drive Main Control Board
255 . 255 . 255 . 255
[Subnet Cfg 1]
[Subnet Cfg 2]
[Subnet Cfg 3]
[Subnet Cfg 4]
