Chapter 7 Control Bay and Control Pod Components
6. Loosen the two captive thumb screws that secure the board and fiber-optic
cables to the chassis and remove the board and cables.
7. For each fiber-optic cable, remove the cable from the transceiver.
8. For each fiber transceiver board, remove the transceivers from the
connector on the board. Retain the transceivers for reuse.
6
–
T15 or F - 5 mm (0.19 in.)
0.45 N
•m (4 lb•in)
=
7
8
=
