Rockwell Automation Publication 750-TG100B-EN-P - June 2019 201
Chapter 9
Power Bay Components
This chapter provides detailed instructions for how to remove and replace power
bay components.
Power Bay Kits
Tab le 19 lists the replacement kits available for power bays (frames 8…15).
Table 19 - Power Bay Replacement Kits
Description Catalog Number Identification Identification No. Replacement Instructions
Ventilation Kits
IP54 Exhaust Vent Filter SK-RM-PBFAN-54FLTR1 See Figure 15 on page 204 1See page 211
IP54 Exhaust Fan Fuse SK-RM-INVFAN1-FUSE 2 See page 212
IP54 Exhaust Fan SK-RM-PBFAN1-F8 3 See page 214
IP54 Door Filter (400 mm) SK-RM-PB4DR-54FLTR1 4 See page 220
IP21 Door Filter (400 mm) SK-RM-PB4DR-21FLTR1 5 See page 221
IP54 Door Filter (600 mm) SK-RM-PB6DR-54FLTR1 4 See page 220
IP21 Door Filter (600 mm) SK-RM-PB6DR-21FLTR1 5 See page 221
IP54 Door Filter (800 mm) SK-RM-PB8DR-54FLTR1 4 See page 222
IP21 Door Filter (800 mm) SK-RM-PB8DR-21FLTR1 5 See page 222
DC Precharge Module Kits
DC Precharge Module Disconnect Handle
and Shaft
SK-RM-DCPC-HNDL See Figure 16
on page 205 6See page 222
DC Precharge Circuit Board SK-RM-DCPC1-CD (400V/480V)
SK-RM-DCPC1-EF (600V/690V)
7See page 229
DC Precharge Fuses SK-RM-DCFUSE1-F8 (400V/480V)
SK-RM-DCFUSE2-F8 (600V/690V)
8See page 233
Power Module Kits
