Rockwell Automation Publication 750-TG100B-EN-P - June 2019 155

Control Bay and Control Pod Components Chapter 7

Backplane Circuit Board

Replacement

Replace a control pod backplane circuit board with kit catalog number

SK-RM-PODBP1.

Remove the Backplane Circuit Board

Follow these steps to remove the backplane circuit board.

1. Review the Product Advisories on page 14

2. Remove power from the system. See Remove Power from the System on

page 15

3. Open the control bay enclosure door.

4. Remove the control pod cover. See Control Pod Cover Removal on page

146

5. Remove the main control circuit board. See Main Control Circuit Board

Replacement on page 152

6. Disconnect and remove any option modules from the backplane circuit

boards.
