Rockwell Automation Publication 750-TG100B-EN-P - June 2019 55

Chapter 4

Frame 5 Components

This chapter provides detailed instructions for how to remove and replace

frame 5 PowerFlex® 755T product components.

Frame 5 Kits

Tab le 8 lists the replacement kits available for frame 5 PowerFlex 755T products.

Table 8 - Frame 5 Replacement Kits

Description Catalog Number Replacement Instructions

Power Module Components

Power Feedback Circuit Board and Bracket SK-RM-PFB-F5-F6 See page 67

LCL Filter Module Components

Capacitor SK-RM-LCLCP4-F5 (400/480V) See page 71

SK-RM-LCLCP6-F5 (600/690V)

Control Pod Components

Main Control Circuit Board SK-RM-MCB1-PF755 See page 57

Cooling Components

Stirring Fan Assembly SK-RM-MFAN1-F5 See page 61

Heatsink Fan Assembly SK-RM-HSFAN1-F5 See page 62

Fan Power Supply Circuit Board SK-RM-PSB1-F5-F6 See page 64

Accessories Kits

Potential Earth (PE) Jumper SK-RM-JMPR1-F5 See page 66
