Preventative Maintenance Chapter 2
Cabinet (IP21/IP54),
Frames 7…15
(1)
Door-mounted Ventilation Air
Filters
C/R C/R C/R C/R C/R C/R C/R C/R C/R C/R C/R C/R C/R C/R C/R C/R C/R C/R C/R C/R C/R
Roof-mounted Ventilation
Assembly Air Filters
C/R C/R C/R C/R C/R C/R C/R C/R C/R C/R C/R C/R C/R C/R C/R C/R C/R C/R C/R C/R C/R
Input Bay Fans -
Frames 8…15 only
Port 0: 523
I I I I I I I I I I I I I I I I I I I I
Power Bay IP54 Roof Fan Port 0: 533 I I I I I I I I I I I I I I I I I I I I
Wiring Bay Fan -
Frames 8…15 only
Port 0: 543
I I I I I I I I I I I I I I I I I I I I
Control Bay Roof Fan -
Frames 8…15 only
Port 0: 553 I I I I I I I I I I I I I I I I I I I I
Isolation Transformer/Line Reactor M M M M
DC Link/Common-Mode Choke M M M M
Control Pod Assembly Control Pod Cooling Fan -
Frames 7…15
(cat. no. SK-RM-PODFAN1-F8,
SK-RM-PODFAN-F7)
Port 0: 513
I I I I I I I I I I I I I I I I I I I I
Main Control Circuit Board
(cat. no. SK-RM-MCB1-PF755)
R
Dual Transceiver Circuit Board -
Frames 7…15
(cat. no. 20-750-MFTB1-F8)
R
Fiber Interface Circuit Board -
Frames 7…15
(cat. no. SK-RM-FIBn-F8)
R
Backplane Circuit Board
(cat. no. SK-RM-PODBP1)
R
Fiber-optic Cables IIIIRIIIIRIIIIRIIIIR
Enhancements Firmware - - Rv - - Rv - - Rv - - Rv - - Rv - - Rv - -
Hardware - - Rv - - Rv - - Rv - - Rv - - Rv - - Rv - -
Table 3 - Recommended Maintenance Schedule for Normal Operation (Continued)
Years > 01234567891011121314151617181920
Module/Activity Component Predictive
Maintenance
Parameters
To Next Page
