92 Rockwell Automation Publication 750-TG100B-EN-P - June 2019

Chapter 5 Frame 6 Components

6. Loosen the M5 hexagonal screws that secure the capacitor wires to

terminals R, S and T on the capacitor terminal block at the top of the

capacitor, and remove the wires. Retain all wires for reuse.

Resistor

Interconnection

Wires

From Power

Circuit Board

3 mm

1.8 N

•m (16.0 lb•in)
