Roland BRIDGE CAST X User Manual

Adjusting the volume (home screen)
30
For the mic audio (not routed through a bus) and PERSONAL MIX, use the BRIDGE CAST app to set
which one is being controlled on this unit.
MIX LINK button
Links/unlinks the two buses (STREAM MIX, PERSONAL MIX). This works the same as the [MIX LINK]
button on the BRIDGE CAST X.
When the link is on, you can adjust the input level while retaining the volume balance for each bus.
* When the input source is “MIC”, the MIC audio (not routed through a bus), STREAM MIX bus
and PERSONAL MIX bus are linked.
MUTE/ASSIGN button
functions
This sets the functions for the MUTE/ASSIGN [1]–[4] buttons.
CH MUTE ALL (*3)
Mutes/unmutes audio for the channels routed to the STREAM MIX
and PERSONAL MIX buses.
When the input source is “MIC”, this mutes/unmutes the mic audio
(not routed through a bus) and the mic audio routed to the STREAM
MIX/PERSONAL MIX buses.
CH MUTE TO STREAM MIX
(*3)
Mutes/unmutes audio for the channels routed to the STREAM MIX
bus.
CH MUTE TO PERSONAL MIX
(*3)
Mutes/unmutes audio for the channels routed to the PERSONAL
MIX bus.
Mutes/unmutes the mic audio (not routed through a bus) and the
mic audio routed to the PERSONAL MIX bus, when the input source
is “MIC”.
SFX A, SFX B
Plays the sound effect registered for SFX A or SFX B.
You can register a music file (.wav) that you like to SFX A and SFX B.
â Registering a sound effect(P.31)
SFX BEEP
Plays a beep sound.
MUTE OUTPUT ALL
Mutes all output audio.
MUTE STREAM OUT
Mutes/unmutes audio for the STREAM MIX bus audio that’s output
from the USB port.
MUTE LINE OUT
Mutes/unmutes the audio output from the LINE OUT jack.
MUTE PHONES
Mutes/unmutes the headphone or headset audio.
PROFILE 1–5
Switches between profile 1–5.
GAME EQ 1–5
Recalls equalizer presets 1–5.
GAME EQ OFF
Turns the equalizer off.
MIC EFFECTS 1–5
Recalls mic effect presets 1–5.
MIDI CC 1–4 (*1)
Transmits MIDI control change messages 1–4 from the MIDI output
port (CTRL) of the USB port.
SOUND EFFECTS A (BGM
CAST)–SOUND EFFECTS D
(BGM CAST)
Plays back the sound effects you selected for SOUND EFFECTS A–D.
â Using sound effects(P.88)
LED color slider
Sets the color of the CH1–4 indicators.
The color of the CH 1–4 indicators and LEDs change according to the motion of the LED color slider.
Input source
Assigns input sources to the CH [1]–[4] knobs on this unit.
Use the CH [1]–[4] knobs on this unit to change the volume of the assigned input sources.
MIC
The audio of the dynamic mic, condenser mic connected to the MIC
jack, or the audio of the headset mic connected to the
PHONES/HEADSET jack
* When this is set to “MIC”, you must select the mic type.
â Selecting the type of mic(P.34)
AUX
Audio input from the AUX jack
CHAT (*1)
GAME (*1)
MUSIC (*1)
SYSTEM (*1)
CONS/MOBI (*2)
Audio input from the USB port
SFX
Sound effects (SFX A, SFX B, SFX BEEP)
HDMI
Audio input from HDMI IN 1, 2 connectors
SFX volume setting
button
A popup window for setting the volume of SFX A and SFX B appears.
To adjust the volume balance between SFX A and SFX B, use the SFX A or SFX B slider (adjustable
from 0 to 100).
