Main specifications
92
Main specifications
1280 x 720/50p, 59.94p, 60p, 100p, 119.88p, 120p (CTA-861-F)
1920 x 1080/23.98p, 24p, 25p, 29.97p, 30p, 50p, 59.94p, 60p, 100p, 119.88p, 120p (CTA-861-
F)
2560 x 1080/23.98p, 24p, 25p, 29.97p, 30p, 50p, 59.94p, 60p, 100p, 119.88p, 120p (CTA-861-
F)
3840 x 2160/23.98p, 24p, 25p, 29.97p, 30p, 50p, 59.94p, 60p (CTA-861-F)
1280 x 720/60 Hz (VESA DMT)
1920 x 1080/60 Hz (VESA DMT)
2560 x 1440/60 Hz (VESA CVT Reduced Blanking)
2560 x 1080/60 Hz (VESA CVT Reduced Blanking)
3440 x 1440/60 Hz (VESA CVT Reduced Blanking)
1920 x 1080/240 Hz
2560 x 1080/144 Hz
2560 x 1440/144 Hz
3440 x 1440/100 Hz
* The listed refresh rate (Hz) is the maximum value of each resolution.
* HDR (High Dynamic Range) Supported
(When using USB video output)
1280 x 720/50p, 59.94p, 60p (CTA-861-F)
1920 x 1080/29.97p, 30p, 50p, 59.94p, 60p (CTA-861-F)
3840 x 2160/29.97p, 30p, 50p, 59.94p, 60p (CTA-861-F)
YUY2 (Uncompressed), Motion JPEG (Compressed)
USB Video Output Resolution
1920 x 1080, 1280 x 720, 640 x 480
* Maximum frame rate is 60 fps.
AUX
HDMI (*1)
USB CHAT (*2)
USB GAME (*2)
USB MUSIC (*2)
USB SYSTEM (*2)
CONSOLE/MOBILE (*3, *4)
(*1) Linear PCM 48 kHz, 2 ch, 5.1 ch, 7.1 ch
(*2) When the USB port connection setting is “PC”
(*3) When the USB I port connection setting is “CONSOLE/MOBILE”
(*4) When the USB II port connection setting is “MOBILE”
PHONES
AUX (*5)
USB MIC (*5)
USB STREAM (*6)
USB PERSONAL (*6)
USB CONSOLE/MOBILE (*7, *8)
(*5) Microphone audio is output from the CTIA MIC jack
(*6) When the USB port connection setting is “PC”
(*7) When the USB I port connection setting is “CONSOLE/MOBILE”
(*8) When the USB II port connection setting is “MOBILE”
2 (STREAM MIX, PERSONAL MIX)
