Roland BRIDGE CAST X User Manual

Main specifications
93
Effects
MIC
Voice Changer, Noise Suppressor, Compressor, Equalizer, De-esser,
Reverb, Low Cut
CHAT
De-esser, Compressor
HDMI
Equalizer, Virtual Surround
GAME
Equalizer, Virtual Surround
STREAM
Delay
Audio File Player
Number of tracks
2
Data Formats
WAV (Linear PCM, 48 kHz, 16 bits, stereo/mono)
Maximum Time
5 seconds/track
Input Level
MIC
-87– -12 dBu (Maximum: 0 dBu)
HEADSET MIC
-56– -12 dBu (Maximum: 0 dBu)
AUX
-10 dBu (Maximum: +2 dBu)
Input Impedance
MIC
8 kΩ
HEADSET MIC
1.3 kΩ
AUX
10 kΩ
Output Level
LINE OUT
0 dBu (Maximum: +12 dBu)
PHONES/HEADSET
-1 dBu (Maximum: +11 dBu)
PHONES/HEADSET
78 mW + 78 mW (32 Ω)
PHONES/HEADSET
35 mW + 35 mW (250 Ω)
Output Impedance
LINE OUT
1.1 kΩ
PHONES/HEADSET
10 Ω
AUX (MIC)
940 Ω
Ã
Others
Connectors
MIC jack
XLR type (Phantom power DC 48 V, 6 mA Max)
PHONES/HEADSET jack
Stereo miniature phone type (CTIA, PLUG-IN power)
AUX jack
Stereo miniature phone type (TRRS)
LINE OUT jack
Stereo miniature phone type (TRS)
HDMI IN 1–2, THRU jack
HDMI type A (*9, *10)
USB I port
USB Type-C
®
(*11)
USB II port
USB Type-C
®
(*12, *13)
USB POWER IN port
USB Type-C
®
(*14)
(*9) HDCP Supported
(*10) Multi-format Supported
(*11) Audio/MIDI/HID Supported
(*12) Video/Audio/MIDI/HID Supported
(*13) Capable of supplying power to USB PD (Power Delivery) compatible smartphones
(When 9V/3A is supplied to USB POWER IN jack)
(*14) Requires a USB PD compatible AC adapter capable of supplying 5V/3A or 9V/3A
Power
USB bus power (*15)
USB PD compatible AC adaptor (sold separately)
(*15) Bus-powered operation when connected to USB II port with a PC capable of supplying
5V/3A power
Current Draw
5 V DC, 3 A
9 V DC, 3 A (*16)
(*16) When supplying power to a smartphone connected to USB II port
Operating System
Microsoft Windows 10, Windows 11
Apple macOS 12 or later
Apple iOS 16 or later
* Although Roland has tested numerous configurations, and has determined that on
average, a computer system similar to that described above will permit normal
operation of the BRIDGE CAST X, Roland cannot guarantee that a given computer can
be used satisfactorily with the BRIDGE CAST X based solely on the fact that it meets the
above requirements. This is because there are too many other variables that may
influence the processing environment, including differences in motherboard design
and the particular combination of other devices involved.
Dimensions
269 (W) x 130 (D) x 70 (H) mm
10.6 (W) x 5.1 (D) x 2.8 (H) inches
Weight
1.35 kg
3 lbs
