Replacing Consumable Parts
3
Maintenance
72
2.
Replace the wipers.
Open the right cover.
Preparations are complete when this screen appears.
Touch the location shown in the gure to
discharge any static electricity.
Replace the rst wiper.
Click!
Place the inclined end on
the back side.
If the wiper is installed with the
incorrect orientation, appropriate
cleaning will not be possible.
Hook
Disconnect the hooks.
Using the tweezers to press on the hook in the hole
on the wiper makes it easier to remove the wiper.
Pull up
and out.
Hook
Tweezers (included)
Attaching a new wiper
Removing an old wiper
Attach the part to the hooks.
Be sure to attach the part to the
hooks. Failure to do so may result
in dot drop-out or other problems.
If the area is dark and dicult
to see, use a flashlight or a
similar device to illuminate
the area.
To Next Page
