Contents
Contents
9
Overall Settings for the SPD-SX .......................53
Sound and Performance-related Settings (SYSTEM) .. 53
Master Eect Settings (MASTER EFFECT) ......53
Click Sound Settings (CLICK) ..................54
Input/Output Settings (AUDIO IN/OUT) .......55
Specifying the Kit Switching Order
(KIT CHAIN) ..................................56
Using a Pad or Footswitch as a Switch
(PAD/FS CONTROL) ...........................57
Controlling Images (VISUAL CONTROL) ........57
Initializing the System (SYSTEM INIT) ................58
Display and Pad Settings (SETUP) ...................59
Display Brightness and Indicator Settings
(LCD/LED) ....................................59
Pad Sensitivity Adjustment (PAD SENS) ........ 60
External Pad Settings (TRIG IN) ................62
Footswitch Settings (FOOT SW) ...............63
MIDI Settings (MIDI) ..........................63
Other Settings (OPTION) ...................... 63
Initializing the Setup Parameters (SETUP INIT) .......64
Other Convenient Functions (UTILITY) ..............64
Viewing the Wave List (WAVE LIST) ............64
Importing an Audio File from a USB Flash
Drive (WAVE IMPORT) ........................65
Loading Data from a USB Flash Drive
(LOAD (USB MEMORY)) .......................65
Saving Data to a USB Flash Drive
(SAVE (USB MEMORY)) ........................66
Viewing Information About the SPD-SX Itself
(INFORMATION) ..............................66
Connecting an External MIDI Device ..................67
MIDI Settings for Each Pad (MIDI) ...................67
MIDI Settings for the Entire SPD-SX (MIDI) ...........68
Appendix ............................................69
Troubleshooting ...................................69
Error Message List ..................................70
Specications ......................................71
Index ................................................72
USING THE UNIT SAFELY ..............................74
IMPORTANT NOTES ..................................75
