40
Chapter 4. Effect Settings
These switches allow you to turn all individual effects on/off
within each drum kit.
fig.04-001_70
1.
Press [KIT] - [F4 (FX SW)].
[KIT] lights, and the “EFFECTS SWITCH” screen
appears.
2.
Press [F1]–[F4] to turn the following on/off.
[F1]: Pad Compressor (*1)
[F2]: Pad Equalizer (*1)
[F3]: Ambience
[F4]: Multi-effects
3.
Press [EXIT] to return to the “DRUM KIT”
screen.
* Effect on/off status appears in the “DRUM KIT” screen.
fig.04-002e_70
* 1: All pad compressors or pad equalizers are turned on/off
simultaneously.
An individual Compressor and EQ can be applied to every
sound assigned to a trigger input.
1.
Press [INST] - [F3 (COMP/EQ)].
[INST] lights.
2.
Strike the pad you wish to set.
3.
Press [F2], [F3], or [CURSOR] to select the
parameter.
Function Buttons
[F2 (COMP)]
Pad compressor parameters appear.
[F3 (EQ)]
Pad equalizer parameters appear.
4.
Use [+/-] or [VALUE] to adjust the setting.
5.
Press [F1] and/or [F4] to turn on the
compressor/equalizer for each trigger input.
[F1]:
Turns the pad compressor on/off
[F4]:
Turns the pad equalizer on/off
,
COMP/EQ setting is ON, EFFECTS SWITCH is ON
Effect applies.
,
COMP/EQ setting is ON, EFFECTS SWITCH is OFF
Effect does not apply.
COMP/EQ setting is OFF
Effect does not apply.
* Pressing [F5 (H & R)], you can choose to set the head and rim
simultaneously or individually.
The sound may be distorted in a certain setting.
Effects On and Off Switches
[KIT] - [F4 (FX SW)]
ON OFF
Using the Compressor and
EQ [INST] - [F3 (COMP/EQ)]
