A-19
MODEL 2700 APPENDIX A
SERIAL COMMUNICATIONS PROTOCOL
Type Select Base adr Base adr
Object No. Data Base Adr Type Code Code (hex) (dec)
Sensor 1 Primary Measurement Sensor Data 0 0 08AA 2218
Sensor 2 Primary Measurement Sensor Data 0 1 0AA8 2728
Sensor 3 Primary Measurement Sensor Data 0 2 0CA6 3238
Sensor 4 Primary Measurement Sensor Data 0 3 0EA4 3748
Sensor 5 Primary Measurement Sensor Data 0 4 10A2 4258
Sensor 6 Primary Measurement Sensor Data 0 5 12A0 4768
Sensor 7 Primary Measurement Sensor Data 0 6 149E 5278
Sensor 8 Primary Measurement Sensor Data 0 7 169C 5788
Sensor 1 Type Sensor Config 1 0 0657 1623
Sensor 2 Type Sensor Config 1 1 0668 1640
Sensor 3 Type Sensor Config 1 2 0679 1657
Sensor 4 Type Sensor Config 1 3 068A 1674
Sensor 5 Type Sensor Config 1 4 069B 1691
Sensor 6 Type Sensor Config 1 5 06AC 1708
Sensor 7 Type Sensor Config 1 6 06BD 1725
Sensor 8 Type Sensor Config 1 7 06CE 1742
Sensor 1 Cal Sensor Cal 2 0 0745 1861
Sensor 2 Cal Sensor Cal 2 1 0755 1877
Sensor 3 Cal Sensor Cal 2 2 0765 1893
Sensor 4 Cal Sensor Cal 2 3 0775 1909
Sensor 5 Cal Sensor Cal 2 4 0785 1925
Sensor 6 Cal Sensor Cal 2 5 0795 1941
Sensor 7 Cal Sensor Cal 2 6 07A5 1957
Sensor 8 Cal Sensor Cal 2 7 07B5 1973
Output 1 Source Output 3 0 06FD 1789
Output 2 Source Output 3 1 0721 1825
Alarm 1 Source Alarm 4 0 06DF 1759
Alarm 2 Source Alarm 4 1 06EB 1771
none none Display Source Display 5 0 06F7 1783
none none Dual Measurement Dual Data 6 0 085B 2139
none none Sensor Count System 7 0 0646 1606
TABLE 5. BasesByCode
