A-40
MODEL 2700 APPENDIX A
MODBUS PROTOCOL
TABLE 13. Data (continued)
Data Register Format
Measurement for Sensor5 - Primary 68 Floating-Point
Measurement for Sensor5 - Primary 9 Integer
Measurement for Sensor5 - Secondary 69 Floating-Point
Measurement for Sensor5 - Secondary 70 Floating-Point
Measurement for Sensor5 - Secondary 10 Integer
Measurement for Sensor6 - Primary 71 Floating-Point
Measurement for Sensor6 - Primary 72 Floating-Point
Measurement for Sensor6 - Primary 11 Integer
Measurement for Sensor6 - Secondary 73 Floating-Point
Measurement for Sensor6 - Secondary 74 Floating-Point
Measurement for Sensor6 - Secondary 12 Integer
Measurement for Sensor7 - Primary 75 Floating-Point
Measurement for Sensor7 - Primary 76 Floating-Point
Measurement for Sensor7 - Primary 13 Integer
Measurement for Sensor7 - Secondary 77 Floating-Point
Measurement for Sensor7 - Secondary 78 Floating-Point
Measurement for Sensor7 - Secondary 14 Integer
Measurement for Sensor8 - Primary 79 Floating-Point
Measurement for Sensor8 - Primary 80 Floating-Point
Measurement for Sensor8 - Primary 15 Integer
Measurement for Sensor8 - Secondary 81 Floating-Point
Measurement for Sensor8 - Secondary 82 Floating-Point
Measurement for Sensor8 - Secondary 16 Integer
Sensors Active 18 Integer
Source for Primary Display 49 Integer
Units - Dual 50 Integer
Units for Primary Measurement and Type for Sensor1 33 Integer
Units for Primary Measurement and Type for Sensor2 35 Integer
Units for Primary Measurement and Type for Sensor3 37 Integer
Units for Primary Measurement and Type for Sensor4 39 Integer
Units for Primary Measurement and Type for Sensor5 41 Integer
Units for Primary Measurement and Type for Sensor6 43 Integer
Units for Primary Measurement and Type for Sensor7 45 Integer
Units for Primary Measurement and Type for Sensor8 47 Integer
Units for Secondary Measurement and Type for Sensor1 34 Integer
Units for Secondary Measurement and Type for Sensor2 36 Integer
Units for Secondary Measurement and Type for Sensor3 38 Integer
Units for Secondary Measurement and Type for Sensor4 40 Integer
Units for Secondary Measurement and Type for Sensor5 42 Integer
Units for Secondary Measurement and Type for Sensor6 44 Integer
Units for Secondary Measurement and Type for Sensor7 46 Integer
Units for Secondary Measurement and Type for Sensor8 48 Integer
