A-41
MODEL 2700 APPENDIX A
MODBUS PROTOCOL
Register Format Data
1 Integer Measurement for Sensor1 - Primary
2 Integer Measurement for Sensor1 - Secondary
3 Integer Measurement for Sensor2 - Primary
4 Integer Measurement for Sensor2 - Secondary
5 Integer Measurement for Sensor3 - Primary
6 Integer Measurement for Sensor3 - Secondary
7 Integer Measurement for Sensor4 - Primary
8 Integer Measurement for Sensor4 - Secondary
9 Integer Measurement for Sensor5 - Primary
10 Integer Measurement for Sensor5 - Secondary
11 Integer Measurement for Sensor6 - Primary
12 Integer Measurement for Sensor6 - Secondary
13 Integer Measurement for Sensor7 - Primary
14 Integer Measurement for Sensor7 - Secondary
15 Integer Measurement for Sensor8 - Primary
16 Integer Measurement for Sensor8 - Secondary
17 Integer Measurement - Dual
18 Integer Sensors Active
19 Integer Error Code for Analyzer
20 Integer Error Status for Sensors
21 Integer Error Code for Sensor1
22 Integer Error Code for Sensor2
23 Integer Error Code for Sensor3
24 Integer Error Code for Sensor4
25 Integer Error Code for Sensor6
26 Integer Error Code for Sensor6
27 Integer Error Code for Sensor7
28 Integer Error Code for Sensor8
29 Integer Alarm Status
30 Integer Analog Outputs
31 Integer Analog Output1
32 Integer Analog Output2
33 Integer Units for Primary Measurement and Type for Sensor1
34 Integer Units for Secondary Measurement and Type for Sensor1
35 Integer Units for Primary Measurement and Type for Sensor2
36 Integer Units for Secondary Measurement and Type for Sensor2
37 Integer Units for Primary Measurement and Type for Sensor3
38 Integer Units for Secondary Measurement and Type for Sensor3
39 Integer Units for Primary Measurement and Type for Sensor4
40 Integer Units for Secondary Measurement and Type for Sensor4
41 Integer Units for Primary Measurement and Type for Sensor5
42 Integer Units for Secondary Measurement and Type for Sensor5
TABLE 14. Register
Continued on following page
