Page #92 background image
BRP-Rotax
Operators Manual
CHANGE OF THE CARBURETOR MAIN JET
To change the carburetor main jet, proceed as follows:
Tools required:
Open-end wrench 19 mm
Flathead screwdriver
NOTE
The carburetor must not be removed from the engine in order to change the
jetting.
m WARNING
Non-compliance can result in serious injuries or death!
Handle fuel in well-ventilated areas only.
m WARNING
Non-compliance can result in serious injuries or death!
When handling with fuel, do not smoke or allow open flames. Gasoline and gasoline va-
por are highly flammable and explosive under certain conditions.
m WARNING
Risk of fire and explosion!
Make sure that fuel will not splash onto hot engine components or equipment.
ENVIRONMENTAL NOTE
Don’t spill fuel. Absorb spilled fuel with appropriate drying agent and ensure ecological
disposal.
Step
Procedure
1 Drain the fuel in the float chamber into a suitable clean tray by removing the
plug screw (pos. 27) and gasket ring (pos. 26).
NOTE
The fuel drained from the float chamber may be poured back into the
fuel tank.
2
Remove the main jet (pos. 15) and the main jet cup (pos. 14).
NOTE
The size of the jet is imprinted on the face of the main jet.
Effectivity: 125 MAX DD2 evo
3
Page 11
Edition: September 01 2019
