Umbauanleitung/retrofit instruction 125 MAX Series
4. Removal of components
4.1) REMOVAL OF COOLANT HOSES, RADIATOR, RADIATOR BRACKET
4.1.1) Dismantle coolant hoses
 Loosen clamp on coolant hose at the crankcase.
Fig. 2 (K00301)
 Disconnect coolant hose and drain the coolant.
Fig. 3 (K00302)
Seite/page 33/59 Ausgabe/Edition 09/2014
