Rotax 125 Max - 3) Cylinder

Umbauanleitung/retrofit instruction 125 MAX Series
 Remove the combustion chamber insert. Pay attention to the O-ring!
Fig. 21 (K00325)
4.4.3) Cylinder
 Loosen 4 hex. nuts M8 crosswise from cylinder with special tool part no. 676110.
Fig. 22 (K00326)
Seite/page 43/59 Ausgabe/Edition 09/2014
