Rotax 125 Max - 4) Piston, Piston Pin

Umbauanleitung/retrofit instruction 125 MAX Series
4.4.4) Piston, piston pin
 Remove circlip.
Fig. 25 (K00329)
 Press out the piston pin using a screwdriver. Remove needle cage.
 Caution: Risk of damage to the needle cage.
Fig. 26 (K00330)
Seite/page 45/59 Ausgabe/Edition 09/2014
