Umbauanleitung/retrofit instruction 125 MAX Series
Fig. 29 (K00333)
Fig. 30 (K00101)
 Install the piston (1) and piston pin (2) to the conrod (3). See Fig. 31
Fig. 31 (K00335)
 Place the installation tool with the cutout of the circlip down on the piston (1).
 Counter the piston with your hand and press the circlip into it. See Fig. 32.
3
1
2
3
1
2
Seite/page 48/59 Ausgabe/Edition 09/2014
