Rotem Platinum PLUS - Page 38

Poultry House Control
38
Precision Mode Programming Steps
the end & exit menu. Reenter table
to see lines in correct position.
1.8
Control | Feed
Feed Control that matches the
capability of the light table. Program
feed times in the same way by growth
day.
For full feeding, enter a growth day of
1, and leave time settings start at
00:00 and end at 00:00.
See Management, Alarm
Settings for feed alarms and
automatic shut off of feed in
the event of a feed system
malfunction.
1.9
Control | Extra
Systems
Extra systems are four stand alone
simple controllers. Each provides
these basic controls:
1. Start Time: earliest time to activate
output
2. End Time: latest time output can
be active
3. From Temp: temperature above
which output can be active
4. To Temp: temperature below
which output can be active
5. From Humidity: humidity above
which output can be active
6. To Humidity: humidity below
which output can be active
7. On Time (seconds): cycle time, on
setting
8. Off Time (seconds): cycle time,
off setting
1. For 24 hour operation,
leave start and end times at
00:00.
2. For operation, all control
settings must be True. For
example, From Temp must
be below To Temp for
operation.
3. Choose temperature
sensors for extra systems in
Install, Temperature
Definition Menu. Of
course, assign a relay first.
1.10
Control |
Static Pressure
1. Enter low and high pressure limits
for both minimum ventilation and
tunnel ventilation. Note that side
ventilation pressure has low and
high temperature settings for use
with an outside temperature
sensor.
2. Enter low and high pressure alarm
settings.
3. Check the Help | Set parameters:
a) Wind Gust Delay
b) Pressure During Tunnel
1. Transitional Tunnel
permits controller
to open tunnel
curtain in cross
ventilation if the
side vent doors are
already 100% open.
2. Emergency
Pressure is an
automatic response
to high pressure
situations, such as
when a tunnel
curtain fails to
open. By default,
