IQelecCvr
III
Identifying Actuator Parts
Base
Terminal Cover
Stop Bolts
Hand wheel
Control Cover
Conduit entries
Open / Close selector
Motor cover
Local / Remote / Stop
selector
Hand / Auto
lever
Display window
Name plate
Battery sealing plug
Metal (8mm Allen key required)
Plastic (10mm Allen key required)
as appropriate.
