rotork IQT User Manual

80
Heading
AA
Oil
The IQT range are factory filled
with 80% Texaco Texamatic 9330
automatic transmission fluid (ATF)
and 20% Kerosene. Equivalent ATF
lubricants meeting the Dexron
®
2 or
Mercon
®
specification may be used. For
operating ambient temperatures below
-30ºC / -22ºF (Low temperature option
actuators) Texaco 9330 + 80% BP SHF
LT15 should be used.
Food grade lubricating oil is available as
an alternative: contact Rotork.
80
Weights and Measures
12
Actuator Size Nett Weight Oil Capacity
kg/lbs litres/pt.-US
IQT 125 23/51 0.5/1.1
IQT 250 23/51 0.5/1.1
IQT 500 23/51 0.5/1.1
IQT 1000 37/82 0.75/1.6
IQT 2000 37/82 0.75/1.6

rotork IQT Specifications

General

Quarter-turn	Yes
Housing Material	Aluminum alloy
Torque Range	10 Nm to 3000 Nm
Multi-turn	Yes
Linear	Yes
Ingress Protection	IP68
Communication Protocols	Modbus, Profibus, Foundation Fieldbus
Operating Temperature	+70°C
Local Controls	local pushbuttons
Control Modes	Modulating
Display	LCD
Type	Intelligent Electric Actuator
