Fig. 9
The Configuration Settings can be
configured to suit site control and
indication requirements. It is important
that Basic Settings such as limits and
torque switch settings are set before
work commences on commissioning
the Configuration Settings (refer to
page 17).
The layout of the Configuration
Settings accessed with the Setting Tool
are detailed in Fig. 9.1. To successfully
commission the Configuration Settings,
information about the site or process
control system will be required.
The supplied actuator Wiring Diagram
details control and indication devices
fitted to the actuator along with
terminal connection detail and standard
remote control wiring systems.
Power Off Setting
IQT allows settings to be viewed and
set without mains power. To enable
this function, engage handwheel drive
and rotate until the output drive moves
by one turn (refer to page 3).The
Setting-Tool can now be used. As
long as a Setting Tool key press takes
place within the 30 seconds timeout
period, Power Off Setting will remain
enabled. If no infra-red Setting Tool
communication takes place the display
will return to indicating position. The
actuator must then be operated by
handwheel to re-enable Power Off
Setting.
Settings and operation must
be verified by electric operation
and function test of the actuator
to ensure correct operation.
NOTE:
For IQT Battery Failsafe
instructions, see Section 10 page 61.
