61
Actuator Type Setting
9.19
Actuator type determines the speed range and is factory set. Should the actuator
Motor Speed Control PCB be replaced with a spare, the actuator type must be set.
Failure to set the correct type will invalidate the actuator performance specification
and warranty. To set the actuator types go to setting [Ab] in the secondary
functions.
With [Ab] displayed
Use the
+
and
-
key to select the
required actuator type. The selectable
values are related to actuator type as
follows:
Value Type
1 IQT125
3 IQT250
6 IQT500
12 IQT1000
24 IQT2000
PRESS THE KEY.
The displayed value will flash,
indicating that it has been set.
Any value of hex outside of the range
stated will not be accepted into the
actuator memory.
NOTE: Mains power has to be on for
actuator type setting to be carried out.
Positional Display
m
m
P?
k
PC
k
Ir
k
tP
m
Contact Function
cr
k
Contact S1
r1
m
Contact S2
r2
m
Contact S3
r3
m
Contact S4
r4
m
ESD Action
Control Mode
Configuration
A1
m
Extra Indication Remote
Contacts CPT
Control Source
Option Selection OE k OI k Od
m
FL
m
PA
m
IQT Speed IQT Type
Setting Setting
AA k Ab
50
IrDA
comms
Primary
Functions
m
IQT Type
IQT 125
To Next Page
