rotork Mk3 - Page 50

Foundation Fieldbus CP Option Card Technical Manual
50 of 116 Publication PUB089-005-00_0618
Index
Parameter
Description
Range
Default
Units
Class
40
FINAL_VALUE_CUTOFF_LO
Cut-off levels for output
0.0
0
RW
41
LOCAL_FINAL_VALUE_AO
Position Read back Value
0.0-100.0%
N/A
%
RO
42
FINAL_VALUE_DO1
DO Output Value
Hexadecimal 0-0xFF
0
None
RO
43
LOCAL_FINAL_VALUE_DO1
DO Read back Value
Hexadecimal 0-0xFF
0
None
RO
44
FINAL_VALUE_DO2
DO Output Value
Hexadecimal 0-0xFF
0
None
RO
45
LOCAL_FINAL_VALUE_DO2
DO Read back Value
Hexadecimal 0-0xFF
0
None
RO
46
FINAL_VALUE_DO3
DO Output Value
Hexadecimal 0-0xFF
0
None
RO
47
LOCAL_FINAL_VALUE_DO3
DO Read back Value
Hexadecimal 0-0xFF
0
None
RO
48
FINAL_VALUE_DO4
DO Output Value
Hexadecimal 0-0xFF
0
None
RO
49
LOCAL_FINAL_VALUE_DO4
DO Read back Value
Hexadecimal 0-0xFF
0
None
RO
50
Min Position
LRP Min position
0-100%
0
%
RW
51
Max Position
LRP Max position
0-100%
100
%
RW
52
Deadband
Deadband value
0.0-25.5%
5.0
%
RW
53
Hysteresis
Hysteresis value
0.0-25.5%
2.0
%
RW
54
Slow mode range
Range to use slow mode
0-100%
5
%
RW
55
MIT
Motion inhibit timer
0-255s
3
S
RW
56
Comms lost action
Action on comms loss
Value:
0 – No Action
1 – Open
3 – Close
5 – Stop
7 – Position
Any other value = off
0
None
RW
57
Comms lost position
Position on loss of comms
0-100%
0
%
RW
58
Comms Fault timer
FF bus power loss timer
0-255s
10
S
RW
59
Auxiliary Mask (Function)
Monitor or Control
N/O or N/C contacts
0x00-0xFF
0x0F
None
RW
60
HW_DI-4 ESD/Net disable
Selector for ESD function or
Network disable
0- ESD function
1- Network disable
0
None
RW
61
Partial stroke % travel
% position to travel to for
partial stroke
0-100%
95
%
RW
62
Partial stroke limit
Start position for partial
stroke
0 – Close limit
1 – Open limit
1
None
RW
63
Partial stroke timeout
Maximum time for partial
stroke to take
0- 7200s
300
S
RO
64
Partial Stroke Status
Indicates the date and time
for partial stroke test success
and failures
2 Date fields:
Partial Stroke Success
Partial stroke Failure
(MM/DD/YY
HH:MM:SS)
01/01/72
00:00:00
Time
R
