Actuator Input Output Signals
Publication PUB089-005-00_0618 51 of 116
Index
Parameter
Description
Range
Default
Units
Class
65
Control mode
Used for selecting DO4
function
Value:
0 – Positioning mode
1 – ESD
2 – S5 relay operate
3 – Partial stroke with
DO control only
4 – AO only
5 – Two-wire control
6 – Partial stroking with
AO and DO control
0
None
RW
66
Discrete block control
Used to select multiple bit
support for discrete blocks
Bit:
0 – Multiple support
1 – Single support
2 – AO only DI Multiple
support
3 – AO only DI Single
support
0
None
RW
67
Close Torque Set
Datalogger Data
0 – 120%
N/A
%
RO
68
Open Torque Set
Datalogger Data
0 – 120%
N/A
%
RO
69
Torque at 0% - open direction
Datalogger Data – latest
value
0 – 120%
N/A
%
RO
70
Torque at 10% - open direction
Datalogger Data – latest
value
0 – 120%
N/A
%
RO
71
Torque at 20% - open direction
Datalogger Data – latest
value
0 – 120%
N/A
%
RO
72
Torque at 30% - open direction
Datalogger Data – latest
value
0 – 120%
N/A
%
RO
73
Torque at 40% - open direction
Datalogger Data – latest
value
0 – 120%
N/A
%
RO
74
Torque at 50% - open direction
Datalogger Data – latest
value
0 – 120%
N/A
%
RO
75
Torque at 60% - open direction
Datalogger Data – latest
value
0 – 120%
N/A
%
RO
76
Torque at 70% - open direction
Datalogger Data – latest
value
0 – 120%
N/A
%
RO
77
Torque at 80% - open direction
Datalogger Data – latest
value
0 – 120%
N/A
%
RO
78
Torque at 90% - open direction
Datalogger Data Datalogger
Data – latest value
0 – 120%
N/A
%
RO
79
Torque at 100% - open
direction
Datalogger Data – latest
value
0 – 120%
N/A
%
RO
80
Torque at 0% - close direction
Datalogger Data – latest
value
0 – 120%
N/A
%
RO
81
Torque at 10% - close direction
Datalogger Data – latest
value
0 – 120%
N/A
%
RO
82
Torque at 20% - close direction
Datalogger Data – latest
value
0 – 120%
N/A
%
RO
83
Torque at 30% - close direction
Datalogger Data – latest
value
0 – 120%
N/A
%
RO
